Open Stainless Steel Frame High Pressure Compressors
SeaComAir 140 - 265 Stainless Steel Frame Diesel
Models | Motor | Charging Rate* | Refill time* | Pressure | Dimensions LxDxH | Weight | Noise |
|---|---|---|---|---|---|---|---|
Open Frame | Diesel | L/min - scfm | Min | Bar - psi | inch - cm | kg - lbs | dB (ISO3746) |
SCA140DY/6OSS | 6HP Yanmar Diesel | 150 - 6,5 | 12 | 340 - 5000 | 45”(114)x20”(50)x28”(71) | 127 - 279 | 95 |
SCA265DY/9OSS | 9HP Yanmar Diesel | 315 - 14 | 6 | 340 - 5000 | 45”(114)x20”(50)x28”(71) | 155 - 342 | 96 |
Standard Features
Specifications
- Mounted on a free standing, shock mounted, heavy duty Stainless Steel Inox Frame
- Large capacity moisture separators for hot and humid climates
- Oil/water separating chambers (manual drains)
- Breathing air purification system with activated carbon and molecular sieve
- Meets or exceeds all international breathing air standards for CGA Grade“E” Air and DIN EN12021
- Pressure maintaining/Priority back pressure valve
- Pressure relief valve on all stages
- Final pressure relief valve
- Oil filled pressure gauge 0~400bar/5800psi
- Two (2) High Pressure Filling hoses with On/Off filling valve and bleed, depressurize system, with SCUBA INT yoke, DIN200 or DIN300
- Spare parts list and owners manual
- Continuous duty air cooled, three stage three cylinder high pressure air compressor all stainless steel inter- and final-stage coolers
- Max. RPM 1000 - 1550
- Splash lubrication with oil thrower pin
- Oil Capacity 1,7 Liter / 59 oz
- Oil Type SeaComAir synthetic compressor oil ISO VG150
Factory Options
Models | Description |
|---|---|
MP330 | Compressor with 300bar/4350psi max. pressure |
PAC300/100 | Pressure Adapter 300-200bar/4400-3000 psi with MP330 only |
BZTT100 | Hour meter Digital |
IH2/100 | Intake Hose 6' |
*Based on charging an 11 Liter / 80 Cu. Ft. Cylinder from 35 bar / 500 psi to 200 bar / 3000 psi
SeaComAir 140 - 265 Diesel Open Frame are continuous duty compressors.
