Ergo TPS Open Frame High Pressure Compressors


Coltri Ergo TPS 345 ET Electric with Hyperfilters filtering system

ERGO-TPS-345-ET Compressor
ERGO-TPS-345-ET Compressor
Models
Motor
Charging Rate*
Refill time*
Max. Pressure
Dimensions LxDxH
Weight
Noise
Open Frame

Electric

L/min – scfm

Min

Bar – psi

inch – cm

kg – lbs

dB (ISO3746)

Ergo TPS 345 ET

7,5kW 230/400V/50-60Hz 3ph

345 – 14,6

5

340 – 5000

44”(112)x25”(63)x30”(77)

184 – 406

91

Standard Features

Specifications

  • Designed for High Temperature Environment and High Percentage of Humidity
  • Main control panel
  • Pressure maintenance valve
  • Double PED certified Hyperfilter filter system
  • Cabin internal temperature with automatic switch-off
  • Automatic condensate drain
  • Automatic direction of rotation control
  • Electronic pressure switch with automatic shutdown
  • Oil level control with automatic shutdown
  • Oil pump with filter and pressure gauge
  • Automatic condensate drain with tank
  • Carrying handles
  • Interstage Pressure Gauges
  • Breathing air purification system with activated carbon and molecular sieve
  • Meets or exceeds all international breathing air standards for CGA Grade“E” Air and DIN EN12021
  • Two (2) High Pressure Filling hoses with On/Off filling valve and bleed, depressurize system, with DIN200 or DIN300
  • Owners manual
  • Continuous duty air cooled, three stage three cylinder high pressure air compressor all stainless steel inter- and final-stage coolers
  • Max. RPM 1240
  • Oil Pressure Pump Lubrication
  • Oil Capacity 1,7 Liter / 59 oz
  • Oil Type synthetic compressor oil ISO VG150

Factory Options

Models
Description
PAC300/100

Pressure Adapter 300-200bar/4400-3000 psi with MP330 only

Presec

Filter control system

*Based on charging an 11 Liter / 80 Cu. Ft. Cylinder from 35 bar / 500 psi to 200 bar / 3000 psi

Ergo TPS 345 ET Compressor is an continuous duty compressor for stationary operations.
